Formlabs Form Studio 1 - Founders Edition

Pre-Order Available Now

Form Studio 1 is the first affordable, professional-grade resin 3D printer with a powerful, long-lasting print engine and an open platform. Print most parts in under two hours with razor-sharp detail and a workflow that's safe, reliable, and mess-free from start to finish. Paired with Alpha Resins and the Formlabs VOC Extractor, Form Studio 1 is the first and only resin printer with UL GREENGUARD Certification for low chemical emissions.

Specs

Why Choose the Form Studio 1?

Blazing Fast

• Print most parts in less than 2 hours

Safe Printing

• Low-odor, rigorously tested, UL GREENGUARD Gold certified

Amazing Parts

• Razor-sharp details and premium materials

Reliable

• 98% Formlabs print success*

Open

• Print with any resin

_{*Form Studio 1 reliability shows comparable print success to Form 4 that has been independently tested and measured at a 98.7%. Final Form Studio 1 reliability testing is in progress.}

Technical Specs

Light Processing Unit Studio 1 (LPU S1)

Backlight Unit
Release Texture V2
Flexible Film Resin Tank
Intelligent Control Systems
High-Speed Automatic Resin Handling

Backlight Unit: 28 uniform-wavelength LEDs, a plano-convex lens array, and integrated air cooling
405 nm optical wavelength
6 mW/cm² optical power intensity delivered to the cure plane
35 µm pixel size

Up to 130 mm/hour maximum¹
1-30 mm features ±0.5% average (lower limit: ±0.08 mm)
31-80 mm features ±0.2% average (lower limit: ±0.08 mm)
81-150 mm ±0.03% average (lower limit: ±0.08 mm)

Testing in progress, expected to match the 98.7% reliability of Form 4
9 industry-leading Formlabs materials or third-party materials using Open Material Mode (included).
More exciting new materials are currently in development.

20.0 x 12.5 x 23.5 cm
7.9 x 4.9 x 9.3 in
5.9 liters

250 cm²
38.8 in²

29.1 cm
11.5 in

25-250 µm
0.001-0.010 in

PreForm, Dashboard, Formlabs Mobile App

Low-odor resins
Safety data sheets (SDS) available for all resins
Spill-resistant resin tanks
Sealed print chamber
Optional VOC Extractor with chamber vent port for air filtration
UL GREENGUARD Gold certified when used with VOC Extractor and Alpha Resins
