Raise3D Industrial PET CF Filament 1.75mm 1kg Black

Product Description
$109.99
Maximum quantity available reached.

Raise3D Industrial PET CF Filament

Color: Black (PMS: 426C/RAL 7021)

Raise3D Industrial PET CF is a carbon fiber-reinforced composite filament based on PET (Polyethylene terephthalate). Well-dispersed 15wt% carbon fibers enhance the rigidity, strength, heat and chemical resistance of the PET matrix. After annealing, PET CF stabilizes its heat resistance at around 150ºC and tensile modulus and strength of over 6 GPa and 80 MPa respectively. Compared to carbon fiber-reinforced Nylon filament, the high printability, dimensional stability, high creep resistance and low moisture absorption makes PET CF an ideal choice for reliable carbon fiber composite printing for strong and cost-effective end-use applications, such as jigs. fixtures, functional parts.


Please find the slicing profiles of Raise3D Industrial PET CF Filament below:

E2CF: Speed  Standard  High Quality

Pro3 Series/ Pro2 Series/ E2/ N Series: N/A

*Due to the higher carbon fiber content of PET filaments, when printing PET CF, an extra wear-resistant nozzle and extrusion system are required for a consistent printing performance. The E2CF and the RMF500 are specially designed for printing high-performance fiber-reinforced composite filaments. As such, it is recommended to use the Raise3D Industrial PET CF filament exclusively on the E2CF and the RMF500.


Technical Data Sheet

Safety Data Sheet

RoHS – Certificate of Compliance

How to Import Slicing Profile to ideaMaker

Sku: R3D-FL-PET-CF-1.75-1KG-BLK
Vendor: RAISE3D
