| Printing Technology |
Fused Deposition Modeling
|
| Body |
Build Volume (W*D*H) |
Main Nozzle Printing: 256*256*260 mm³
Auxiliary Nozzle Printing: 235.5*256*256 mm³
Dual Nozzle Printing: 235.5*256*256 mm³
Total Volume for Two Nozzles: 256*256*260 mm³
|
| Chassis |
|
|
|
Plastic, Glass, and Metal
|
| Dimensions and Weight |
Physical Dimensions |
|
| Net Weight |
|
| Toolhead |
Main Extruder Gear |
Hardened Steel |
| Main Extruder Motor |
Bambu Lab High-precision Permanent Magnet Synchronous Motor
|
|
Auxiliary Extruder Gear
|
Hardened Steel
|
|
Auxiliary Extruder Motor
|
Stepper Motor
|
| Nozzle |
Hardened Steel |
| Max Nozzle Temperature |
300 °C |
| Included Nozzle Diameter |
0.4 mm |
Supported Nozzle Diameter
|
0.2 mm, 0.4 mm, 0.6 mm, 0.8 mm
|
| Filament Cutter |
Built-in |
| Filament Diameter |
1.75 mm |
| Heatbed |
Supported Build Plate Type |
Textured PEI Plate, Smooth PEI Plate, Cool Plate SuperTack, Engineering Plate
|
| Max Heatbed Temperature |
120 ℃ |
| Speed |
Max Speed of Toolhead |
1000 mm/s |
| Max Acceleration of Toolhead |
20,000 mm/s² |
Max Flow for Hotend
(Standard Flow Hotend)
|
40 mm³/s
(Test parameters: 250 mm round model with a single outer wall; Bambu Lab ABS; 280 °C printing temperature)
|
Max Flow for Hotend
(Optional High Flow Hotend)
|
65 mm³/s
(Test parameters: 250 mm round model with a single outer wall; Bambu Lab ABS; 280 °C printing temperature)
|
Chamber Temperature Control
|
|
|
|
|
|
|
|
|
G3 |
|
|
|
Activated Carbon Filter Type
|
|
|
|
|
Particulate Matter Filtration
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Chamber Heat Circulation Fan
|
|
Auxiliary Part Cooling Fan
|
|
|
|
|
PLA, PETG, ABS, ASA, TPU, Support for PLA, Support for PLA/PETG, Support for ABS, Support for PA/PET, PET, PA, PC, PVA; Carbon/Glass Fiber Reinforced PLA, PETG, ABS, ASA, PA6, PAHT, PPA, PET
|
|
|
PLA (excluding PLA Aero), PETG, ABS, ASA, TPU for AMS, Support for PLA, Support for PLA/PETG, Support for ABS, Support for PA/PET, PET, PA, PC, PVA; Carbon/Glass Fiber Reinforced PLA, PETG, ABS, ASA, PA6, PAHT, PET
|
Auxiliary Hotend (print with caution¹)
|
PLA Silk, PETG-CF, ASA-CF, PA6-CF, TPU for AMS, Support for PA/PET
|
| Sensor |
|
|
|
|
|
| Door Sensor |
Supported |
| Filament Run Out Sensor |
Supported |
| Filament Tangle Sensor |
Supported |
| Filament Odometry |
Supported with AMS |
| Power Loss Recovery |
Supported |
|
Electrical Requirements²
|
Voltage |
High-voltage version: 200-240 VAC, 50/60 Hz
Low-voltage version: 100-120 VAC , 50/60 Hz
|
|
Max Power³
|
High-voltage version: 1600 W@220 V
Low-voltage version: 1100 W@110 V
|
|
|
High-voltage version:
PLA (25 °C): 250 W@220 V
PC (25 °C): 550 W@220 V
Low-voltage version:
PLA (25 °C): 250 W@110 V
PC (25 °C): 550 W@110 V
|
|
|
|
|
| Electronics |
Touchscreen |
5-inch 1280*720 Touchscreen
|
| Storage |
Built-in 8 GB EMMC and USB Port
|
| Control Interface |
Touchscreen, mobile App, PC App |
|
|
Dual-core Cortex-M4 and Single-core Cortex-M7
|
|
|
Quad-core ARM with dedicated NPU
|
| Software |
Slicer |
Bambu Studio
Supports third-party slicers which export standard G-code, such as Super Slicer, PrusaSlicer and Cura, but certain advanced features may not be supported.
|
| Supported Operating System |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
802.1X Network Access Control
|
|
| Wi-Fi |
Operating Frequency |
2412 - 2472 MHz, 5150 - 5850 MHz (FCC/CE)
2400 - 2483.5 MHz, 5150 - 5850 MHz (SRRC)
|
| Wi-Fi Transmitter Power (EIRP) |
2.4 GHz: <23 dBm (FCC); <20 dBm (CE/SRRC/MIC)
5 GHz Band1/2: <23 dBm (FCC/CE/SRRC/MIC)
5 GHz Band3: <30 dBm (CE); <24 dBm (FCC)
5 GHz Band4: <23 dBm (FCC/SRRC); <14 dBm (CE)
|
| Wi-Fi Protocol |
IEEE 802.11 a/b/g/n |
