EinScan Rigil Lite
The Rigil Series represents the complete form of all-in-one 3D scanners, integrating hardware components such as the scanner, display, computing, storage, and power supply into a unified design, with the entire workflow independently accomplished on-device through software. In Rigil series, the EinScan Rigil Lite offers a cost-effective option that retains core capabilities balancing affordability with essential features for 3D scanning daily works.
Advanced Multi-Tracking Mode (IR & Laser)
Marker-free Laser Scanning
Two-Laser Modes: Crossed-Line Speed, Parallel-Line Detail
Hybrid Light Source
IR VCSEL：Fast, Wide, Eye-Safe, Marker-Free
5MP Texture: Full-color Laser Scanning
Dark & Reflective Surfaces (No Spray)
Outdoor: In Sunlight or At Night. Still Smooth.
Full on-Device Workflow
Scan-to-Design
Multi-Projects Alignment
A new way to scan: Break down complex tasks into small and manageable parts and merge them back to final model.
Scanning Rewind & Resume
Real-time rollback to previous stage, perfect every time.
Auto-Cutting Plane
Automatically identifies and filters out the base surface you don't need.
Flexible Point Clouds Editing
Connect domain & inverse for unnecessary points quick removing, Magnifier tool for clearer, detailed editing.
Rich Mesh Editing Functions
All with one-click operation for rapid model customization.
Advanced Noise Reduction
Deliver crystal-clear data quality and larger volume.
Multi-Coordinate Alignment
Easy to operate with virtually clear results, seamlessly move to model design.
Model Measurement
Quickly retrieve model dimensions — No traditional calipers needed.
U-Drive Mode
Export model as U dish, no software required.
SHINING3D Cloud Sharing
Collaborate and connect in seconds, share your achievement right now!
EinScan Rigil Lite Specifications
| Category | Details |
|---|---|
| Work Mode | Standalone / PC-Wireless / PC-Wired (for extra computing resource) |
| Scan Mode |
Laser HD IR Rapid |
| Light Source |
17+17 crossed blue laser lines 7 blue laser parallel lines IR VCSEL |
| Resolution |
Laser HD: 0.05 ~ 10 mm IR Rapid: 0.2 ~ 10 mm |
| Scan Speed |
17+17 lines: 2,940,000 points/s 7 blue laser parallel lines : 1,620,000 points/s IR Rapid: 16,000,000 points/s |
| Working Distance |
Laser HD: 170 ~ 550 mm IR Rapid: 160 ~ 1500 mm |
| Alignment Mode |
Laser HD: Global Markers / Markers / Features IR Rapid: Markers / Features / Texture / Global Marker |
| Camera Resolution |
3D: 2.3MP*2 1.3MP*2 Texture: 5MP |
| Laser Class |
Laser HD: Class II IR Rapid: / |
| Output Formats | STL, OBJ, PLY, 3MF, ASC |
| Regular Edition Hardware |
CPU: 8-core, 2.4GHz; RAM: 24GB LPDDR5; Storage: 64GB eMMC + 512GB SSD; 6.4-inch 2K AMOLED Touchscreen |
| Limited Edition Hardware |
CPU: 8-core, 2.4GHz; RAM: 32GB LPDDR5; Storage: 64GB eMMC + 1TB SSD; 6.4-inch 2K AMOLED Touchscreen |
| Operating Conditions | Temperature: -10°C ~ 40°C |
| Certifications | CE, FCC, ROHS, WEEE, FDA, SRRC, IP50 |
| Recommended PC Specs |
OS: Win11 (64-bit); Processor: 13th Gen Intel®Core™ i7-13700H or above; Graphics card: NVIDIA GeForce RTX 3060 Laptop GPU or above; VRAM: 8 GB or above; RAM: 64 GB or above, DDR5 dual-channel; Interface: USB 3.0; |
| Interface & Power Source |
USB Type-C |
| Dimensions | (H*D*W) 233 × 180 × 72.8 mm |
| Net Weight | 870 g (with batteries) |
