Flame Retardant Resin is a specialty UL 94 Blue Card-certified material for creating self-extinguishing and halogen-free parts with favorable flame, smoke, and toxicity (FST) ratings. Use FR Resin to easily 3D print flame-retardant, heat-resistant, stiff, and creep-resistant parts that will perform well long-term in indoor and industrial environments with high temperatures or ignition sources.
Tests and certifications include: UL 94 V-0 at 3 mm thickness for flammability; FAR 25.853 Appendix F, Part I for flammability; and ASTM E662 for FST. For full test results and certifications, see the Technical Data Sheet.
Accelerate time to market without the design constraints and upfront costs of traditional manufacturing with isotropic and highly detailed parts (XY resolution: 25um) with unlimited geometric freedom in any quantity (from 1 to 1000 parts) at any time.
Produce certified flame retardant, UL 94 V-0 and FAR-rated 3D printed parts that meet necessary certification requirements for enduring hazardous environments.
Parts will perform well long-term in indoor and industrial environments with high temperatures or ignition sources.
Fabricate plastic parts with exceptional surface finish far superior to other fabrication methods such as FDM 3D printing.
Produce stiff and functional parts with a 2.9GPa modulus that can handle post-fabrication operations such as tapping, trimming, and drilling.
Flame Retardant (FR) Resin is a cost and time-effective solution for fabricating self-extinguishing parts.
| Parameter |
Post-cured at 70 ºC for 60 minutes |
Post-cured at 80 ºC for 120 minutes |
|---|---|---|
|
Heat Deflection Temperature 0.45 MPa |
94 ºC |
111 ºC |
|
Heat Deflection Temperature 1.8 MPa |
71 ºC |
83 ºC |
|
Tensile Modulus |
2.9 GPa |
3.1 GPa |
|
Ultimate Tensile Strength |
38.5 MPa |
41.2 MPa |
|
Elongation at Break |
9.4% |
7.1% |
|
Notched Izod |
22.1 J/m |
22.4 J/m |
| Property | Details |
|---|---|
| Compatible Build Platform | Form 4 Build Platform, Form 4 Flex Build Platform, Form 3 Build Platform, Form 3 Build Platform 2, Form 3 Stainless Steel Build Platform, Form 3L Build Platform, Form 3L Build Platform 2L, Form 4L Build Platform, Form 4L Flex Build Platform, Form Studio Standard Build Platform, Form Studio Flex Build Platform |
| Compatible Tank | Form 4 Resin Tank, Form 4L Resin Tank, Form 3 Resin Tank V2.1, Form 3L Resin Tank V3, Form Studio Resin Tank Pro |
| Compatible Printer | Form 4, Form 4B, Form 4L, Form 4BL, Form 3, Form 3L, Form 3B, Form 3BL, Form Studio 1 |
| Print Technology | SLA |
| Colors | Grey |
| Minimum Layer Thickness | 50 micron |
| Categories | High Stiffness, Temperature Resistant, Specialty |
| Applications | End-Use Parts, Rapid Prototyping |
| Ultimate Tensile Strength | 41.0 MPa |
| Tensile Modulus | 3100.0 MPa |
| Flexural Strength | 75.0 MPa |
| Flexural Modulus | 2700.0 MPa |
| Notched Izod | 22.0 J/m |
| Elongation at Break | 7.1% |
| Heat Deflection Temp. @ 1.8 MPa | 83.0 °C |
| Heat Deflection Temp. @ 0.45 MPa | 111.0 °C |
| Thermal Expansion | 68.1 µm/m/°C |
| Unnotched Izod | 257.0 J/m |
